Arrange welder testing for your job

Tell us what your welders need to be tested for. PWC arranges welder qualification testing (WQT/WPQ) Australia-wide, at your workshop or ours. We can discuss the test requirements and arrangements before you book.

Worker in leather gloves using an angle grinder on steel, with sparks flying

What WQT and WPQ mean

WQT stands for welder qualification test. WPQ stands for welder performance qualification, the term used in ASME codes. Both mean the same thing in practice: a welder makes a test weld, and it’s examined against a standard to show they can produce sound welds with that process, material and position.

A qualification belongs to the welder, but it only covers the range tested: the process, material group, thickness, pipe diameter and positions.

Testing for a clear requirement

Welder testing checks a welder’s work against a stated requirement. Send the standard or customer request, the welding process and the material.

We qualify welders for fusion welding of steels to ISO 9606, AS, ASME, AWS and API requirements. Tests are examined by people holding an IIW welding qualification (IWE, IWT or IWS), AS 2214 welding supervisor certification, CERT 10 or an equivalent.

Welder in a mask welding a steel fabrication, with sparks and smoke

Prepare before the test

We need to agree on the test location, equipment, materials and date. Tell us how many welders need testing and whether you have an existing procedure.

At your workshop

Welders can be tested at your premises. You supply the welding equipment, consumables and test plates, and we agree the test pieces and preparation before the visit.

At our workshop

Welders can also be tested at PWC’s own workshop. The quote explains what is included.

Know which records you will receive

The quote should identify the testing and records included. Tell us if your customer needs a particular form or document.

A record for each welder

Each completed record identifies the welder, the welding process, the material, the test position and the result. It also states the requirements used to assess the test.

ISO 9606 and AS/NZS 2980

In Australia and New Zealand, welders of steel are commonly qualified to ISO 9606-1, with the additional local requirements in AS/NZS 2980. AS/NZS 1554 work generally refers to these. Your customer or contract will say which standard to use.

Other codes have their own welder tests. Pressure equipment to ASME, for example, uses ASME IX. We test to ISO 9606, AS, ASME, AWS and API requirements.

Read more: Welder qualification: ISO 9606 vs AS/NZS 2980

How the test is examined

The finished test piece is checked visually first. Then, depending on the standard, it’s examined further by radiography, bend tests or fracture tests. Tests are examined by people holding an IIW welding qualification (IWE, IWT or IWS), AS 2214 welding supervisor certification, CERT 10 or an equivalent.

Keeping qualifications current

A welder’s qualification has to be kept current. Under ISO 9606-1, a supervisor confirms every six months that the welder has kept working within the range. The qualification is then revalidated every two or three years, or kept valid through a certified ISO 3834 system, depending on the option chosen.

We can track renewal dates for your welders and retest them when needed.

Welders we’ve tested

PWC has carried out welder qualification for NWEC, Karuah, TTM Engineering and Veolia, among others.

Is this the same as training?

Training helps people learn or improve a skill. A qualification test checks whether a welder meets the stated test requirements. Let us know if your staff need preparation as well as testing.

Common questions

Tell us about your welders

Send the number of welders, process, material, standard and preferred date.
